Factory Price for Fully Automatic Pharmaceutical Hard Gelatin
Capsule Filling Machine
Quick information
1. Working steady, safe and reliable enough.
2. Capsule qualified rate is more than 99% with the precise dosage.
3. Timing frequency-conversion, programmable controlled.
4. New closed structure, accord with GMP standard.
Technical Parameter
| Machine Model | NJP- 400C |
| Control | PLC stepless frequency inverter |
| Operation | Control by touch screen |
| Filling dosage | Powder ,Pellets |
| Capsule size | 00#---4# capsule exculde 3# |
| Max Output | 24000 Capsules/hour |
| Power | 380V/50Hz 3KW can customized as per customer's requirement |
| Noise index | <80dba |
| Overall Dimensions | 700*900*1800 mm (L*W*H) |
| Net weight: | 700kg |
| Attachment | A vacuum pump, a deduster, water tank, a powder collecting box, and
a set of mould. |
Performance and characteristic
Small volume, low energy consumption, fast mould change, convenient
operating, easy cleaning.
The rate of capsule filling is 99%
Shelter are fixed around the dose pan which can recycle the power
,reduce the dust on the working bench.
The turning-around parts are in full closure, have excellent
lubricating conditions.
Adopt the man -machine interface, including PLC programming
controller, appear the capacity of per minutes, total output,
dynamic empty capsules and medicine powder condition, alarm for
capsule lacking, and automatically stop for lacking of medicine
power, breakdown diagnosing display.
Description
1.The working station cam runs under the good lubricating
condition, increase the pressure spray pump, maintain the
lubrication of cam slot, reduce wear, longer the service life of
spare parts.
2.It adopt computer controller, has frequency conversion, digital
display makes an easy operation and clear appearance.
3.The multi-bore dosing, which ensure the high precision dosage (it
is controlled around ±3.5%); if user use good capsule, the capsule
qualified rate can achieve ≥99.9%). The machine is suitable for
Chinese traditional medicine and the Western medicine.
4.It is equipped with safely protection device and automatic
shutdown against the lack of materials. It runs steady and
reliable; it is the best choice for the hard capsule filling.
Machine Making Process
Questions and Answers
Q : How about the after-sales service ?
A:Our machine have one year guarateen, life long mantainance.
We have a strong team special for after sales. We can arrange
engineer to do service for you.
Q: are you a factory or trading company?
A: we are a factory in this field nearly 15 years ( early named
Ruian Huali Pharmaceutical Machinery Factory)
Q: How does your factory do regarding quality control?
A: Quality is our invariable topic. It’s the basement of company’s
development.
From beginning of company opening, we are especially focus on
quality job.
Our pharmaceutical equipment have passed the GMP certification, ISO
international quality system certification, CE certification and
gain several utility model patents and invention patents issued by
state patent office of China.
Q: what information should I let you know when I want to get
quotation?
A: - the size of your capsules,the target capacity you want the
machine meet. The more information the better.
