Name: Customized Large Automatic Capsule Filling Machine 00# 0# 1#
2# 3# 4#
Capsule Machinery Characteristic:
1. Working steady, safe and reliable enough.
2. Capsule qualified rate is more than 99% with the precise dosage.
3. Timing frequency-conversion, programmable controlled.
4. New closed structure, reached GMP standard.
Main Features:
1. This Large capsule filler machine has been improved the inner
design turret,and imports bearing for each machine from Japan
directly, so that it can be sure a longer usage life and precision
of the machine.
2. The working station cam runs under the good lubricating
condition, and maintains the inner lubrication of cam slot to a
full extent, increasing the pressure pulverization oil pump, thus
extends the operation life of the spare parts.
3. It adopts enlarged Cam,“HUALE”has become the one who matches the
cam of RU125 to RU1OO,while it enhances the
stability of the machines and extends the life of the machines to a
great extent.
4. It is controlled by the computer, has as stepless timing with
the frequency conversion the numeral showing makes an easy
operation and clear appearance.
5. The multi-bore dosing bring a precision dosage (it is controlled
around ±3.5%) ; the good capsule applicability makes a high
capsules qualified rate more than 99%.It can be filled with the
Chinese traditional medicine and the western medicine.
6. Add the extra function of capsule control switch. Control the
capsule outside of the machine, it is more safely and quickly.
7. Add the click-moving control system,makes an easier operation
and clearness.
Specifications
Item | NJP-3500 |
Output | 210000 capsules/h |
Bores | 25 |
Rate of capsule filling | 99% |
Appropriate for capsule | 00#-4# |
Total Power | 10.5kw |
Noise standard | ﹤75dB(A) |
Fining Precision | >99.9% |
Weight | 2200kg |
Dimension | 1000*1300*1900mm |
WARRANTY
- Technical Support(24 hours on line support by emails, skype, MSN,
mobile).
- Loading inform(loading port, destination port, shipping date, CBM,
weight, etc.)
- Video for debugging after sent products.
- Pre-maintance.
- Quality guarantee for 1 year. Within warranty period, we provide
spare parts for replacement free if not man-factor.
- Welcome send us samples to test on our machine and we will take
video for you to confirm.
- Welcome visit our factory for checking machine and offer training
course for your workers.
Questions and Answers
Q : How about the after-sales service ?
A:Our machine have one year guarateen, life long mantainance.
We have a strong team special for after sales. We can arrange
engineer to do service for you.
Q: are you a factory or trading company?
A: we are a factory in this field nearly 15 years ( early named
Ruian Huali Pharmaceutical Machinery Factory)
Q: How does your factory do regarding quality control?
A: Quality is our invariable topic. It’s the basement of company’s
development.
From beginning of company opening, we are especially focus on
quality job.
Our pharmaceutical equipment have passed the GMP certification, ISO
international quality system certification, CE certification and
gain several utility model patents and invention patents issued by
state patent office of China.
Q: what information should I let you know when I want to get
quotation?
A: - the size of your capsules,the target capacity you want the
machine meet. The more information the better.
